Delta 36-6010 Portable Table Saw
- Unique tubular frame for maximum support and stability
- Aluminum table top with RH table extension.
- Large, easy to access ON/OFF switch
- Industry Standard tool-free split guard design allows a true rise-and fall riving knife by using a lever on the inside the throat plate.
- Tool-less assembly of riving knife and anti-kickback pawls.
- Blade retracts below table top for easy clean-up of table top.
- CULus Listed
Specifications:
- Motor: 15 Amp Induction Motor, 1 PH, 60 Hz
- Voltage: 120V
- Speed: 5000 RPM
- Arbor: 5/8 in.
- Blade Tilt: 45° Left
- Max. Depth of Cut at 90°: 3 ½ in.
- Max. Depth of Cut at 45°: 2 ½ in.
- Max. Rip Right of Blade: 30 in.
- Max. Rip Left of Blade: 7 ¼ in.
- Table Size: 19.56 in. wide X 26 in. deep
- Table Coating: Yes, Anti-Friction
- Dado Capacity: 13/16 in. X 8 in. STACKED DADO
- Dust Port Size: 2 ½ in.
- Width with Fence: 47 ¼ in. .
- Height: 14.62 in.
- Depth : 36 7/16 in.
